Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+ PORT: 24× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 2× Gigabit SFP Ports SPEC: 802.3at/af, 384W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller
1.437,99 RON
(TVA inclus)
2.494,68 RON
pret valabil pana la 29 sept.
Plata card comison 0! Rate 0% dobanda plata card de cumparaturi!
Descriere
Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+ PORT: 24× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 2× Gigabit SFP Ports SPEC: 802.3at/af, 384W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller and Omada Cloud Essentials, Fast PoE, Perpetual PoE, Flow Control, Loopback Detection, Port Isolation, Port Mirroring, LAG, VLAN, IGMP Snooping, QoS, Storm Control
Detalii
SKU
ES228GMP
EAN
1210002600989
Categorii
Brand
Rackable
No
Stackable
No
LAN-Port-Type
FastEthernet
LAN-Ports
8
Redundant-PSU
No
LED indicators
Yes
Product colour
Black
Manual
Yes
Storage temperature (T-T)
-40 - 70 C
Quick start guide
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Operating relative humidity (H-H)
10 - 90%
Cables included
AC
Housing material
Metal
Height
44 mm
Storage relative humidity (H-H)
5 - 90%
Number of fans
2 fan(s)
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Depth
330 mm
Jumbo frames support
Yes
Rack mounting
Yes
Quality of Service (QoS) support
Yes
Flash memory
64 MB
Switch type
Managed
Power over Ethernet (PoE)
Yes
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power source
AC
Power supply included
Yes
IGMP snooping
Yes
Store-and-forward
Yes
Flow control support
Yes
VLAN support
Yes
Web-based management
Yes
Auto MDI/MDI-X
Yes
Link aggregation
Yes
SFP module slots quantity
2
MAC address table
8000 entries
Switch layer
L2
Multicast support
Yes
10G support
No
Width
440 mm
Power over Ethernet (PoE) power per port
30 W
Port mirroring
Yes
DHCP features
DHCP client
Switching capacity
56 Gbit/s
Firmware upgradeable
Yes
Broadcast storm control
Yes
Rack mount kit
Yes
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Cloud-managed
Yes
Power over Ethernet (PoE) type supported
PoE+
Surge protection
Yes
Forwarding rate
41.66 Mpps
Fanless
No
Packet buffer memory
4 MB
Virtual LAN features
MTU VLAN, Port-based VLAN, Tagged VLAN
Unified static configuration
Yes
Operating temperature (T-T)
-5 - 45 C
Certification
FCC, CE, RoHS
Number of VLANs
32
Total Power over Ethernet (PoE) budget
384 W
Power over Ethernet plus (PoE+) ports quantity
24
Jumbo frames
15000
Basic switching RJ-45 Ethernet ports quantity
26
Gigabit Ethernet (copper) ports quantity
26
Surge protection voltage
6 kV
Mean time between failures (MTBF)
224143 h
Fast leave
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X
Heat dissipation
1546.15 BTU/h
Noise level
46.2 dB
Power consumption (max)
454.8 W
Queue scheduling algorithms
Weighted Round Robin (WRR)
